2 Power 1 Grounding IP67 Electrical Connectors 5 Data Combined For Lithium - Ion

2 Power 1 Grounding IP67 Electrical Connectors 5 Data Combined For Lithium - Ion

Brand Name : Jnicon
Model Number : M19
Certification : TUV,UL,CE,CQC
Place of Origin : Shenzhen,China
MOQ : 1 pair
Price : Negotiable
Payment Terms : T/T, Western Union, , D/P, D/A, L/C, MoneyGram
Supply Ability : 10000 sets / Day
Delivery Time : 3~5 working days
Packaging Details : 1.Plastic bag;2.Carton;3.As per customer's requirements
Connecting model : Screw locking
Contact Pin : 8Pin
Color : Blue/Black
Current Rating : 20A
Contact Now

2 Power 1Grounding IP67 Waterproof Connector 5 Data Combined For Lithium-Ion Systems


Description of 2power 1 grouding 5 data combined connector


Push locking waterproof connector IP67 is the main feacture of Jnicon M19 model. Its take only a few seconds to connect the male female connector, thanks to its advanced structure . it is widely used in many application. If your application is similar to the below, this 2power 1 grouding 5 data combined connector will be a good choice


Application of waterproof quick connectors


  • Lithium-Ion Systems
  • Communications Application
  • product coding machines
  • inventory product coding
  • inkjet systems
  • Solar System
  • industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic&pathology equipment
  • Communications equipment
  • Heavy machinery

Main characteristics


  • Sealed against dust and fluid (IP67)
  • Vibration resistance,impact resistance,stretching resistance
  • socket with cover
  • Cable assembly support
  • Customized cable size and length

Features:


  • 2-4PIN power supply, 5-9PIN signal is optional.
  • IP67/68 rating
  • Voltage rating: 300V
  • Cable Range: 3~11mm
  • UL, TUV, CB, CCC, CE, RoHS approved

Technical Parameters
Contact Resistance10 mΩ max
Insulation Structure500 MΩ at 500VDC
Operating Temperature-40°C ~ +105°C
IP ClassIP67 (1m / 30min)
Mold MaterialPA66
Contact/Terminal MaterialGold Plated Brass
Seal MaterialSilicone

Operation Parameters
Voltage Rating500VAC max
Min Wire Size OD3.0mm ~ 6.5mm
Max Wire Size OD6.5mm ~ 10mm
Max.Cable Cross Section Area0.3mm2 ~ 2.5mm2

FAQ


1. Q: What type waterproof connector do you have?
A: We have 17series type connector,and make more than 3000types waterproof connector cable.Most of our connector is customized.We foucs on LED Waterproof connector,Assembly waterproof connector,Over-mold waterproof connector,T waterproof connector,Y customized waterproof connector.

2. Q: How to buy your products?
A: You need to do as followings:
* Confirm Current Rating and Number of Contacts
* Confirm Assembly style
* Confirm Cable Wire guage
* Confirm Cable Length and shipping way

3. Q: How to contact with you?
A: Please give us email,we have worked for this industry more than 10 years,So we can catch your problem,and solve it in a short time.if you have any question please feel free to let us know.
